5-Port Unmanaged Fast Ethernet Switch with Single-mode Fiber, SC connector, 15 KM, plastic housing
Availability : 2-3 weeks
EH2005-Fs
Availability : 2-3 weeks
EH2005-Fs
| Ethernet | |
| Connector | RJ-45 |
| Port(s) | 4 |
| Transmission Rate | 10/100 Mbps |
| Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/ 100BASE-FX |
| Auto MDI/MDI-X | Yes |
| Optical Fiber | |
| Connector | ST (EH2005-Fm) / SC (EH2005-Fs) |
| Port(s) | 1 |
| Transmission Rate | 100 Mbps |
| Fiber Type | Single-mode (EH2005-Fs) Multi-mode (EH2005-Fm) |
| Cable Requirements | 9/125μm (EH2005-Fs) 50/125μm, 62.5/125μm (EH2005-Fm) |
| Fiber Wavelength | 1310nm |
| Tx Output Power | -7 ~ -15 dBm (EH2005-Fs) -14 ~ -19 dBm (EH2005-Fm) |
| Rx Sensitivity | -32 dBm |
| Fiber Distance | 20km (EH2005-Fs) 2km (EH2005-Fm) |
| Power | |
| Connector | 5.08mm 3-pin Terminal Block |
| Input Voltage | 9-30 VDC |
| Input Current | 0.60A |
| Power Consumption | 5.4W max. |
| Reverse Polarity Protection | Yes |
| Redundancy | Yes |
| Approval | |
| EMC | FCC Class A, CE Class A |
| EMS | ESD Level 2, RS Level 2, EFT Level 2, Surge Level 2, CS Level 2, PFMF Level1, DIP. |
| Safety | UL60950-1 |
| Protection | IP40 |
| Environment | |
| Operating | 0°C~60°C (32°~140°F) |
| Storage | -20°~70°C (-4°~158°F) |
| Humidity | 5~95%RH(Non-condensing) |
| Mechanical | |
| (W x H x D) | 45mm x90mm x 80mm |
| Material | Plastic |
| Installation | Wall mount, DIN Rail |
| Reset Button | No |
| Weight | 155g |
| Warranty | 5 years |
