| Code: | Z-PASS2-4GWW |
| Description: | Industrial Gateway with VPN support - Serial Device Server with integrated I/O, GPS receiver and 4G modem |
| Power supply: | 19..40 Vdc; 19..28 Vac |
| Power Consumption: | Typical 4 W @ 24Vac, Max 6 W |
| Insulation: | 1.500 Vac |
| Status indicators: | Power supply/Ready to use Input/output status Remote Connection (RCD) VPN Connection (VPN) LAN/WAN (Ethernet LAN/WAN mode) SERV (VPN BOX Service) Rx-Tx Communications |
| Operating modes: | Bridge Gateway Router ETH/3G+ (redundant connection) Remote Virtual COM Tunnel P2P/P2MP/TCP/UDP VPN |
| Bands supported 4G LTE | LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28 LTE-TDD: B38/B39/B40/B41 WCDMA: B1/B2/B4/B5/B6/B8/B19 GSM: B2/B3/B5/B (for more information please see user manual) Modem certifications: Deutsche Telekom (Europe) Verizon*/AT&T*/T-Mobile*/Sprint* (North America) |
| I/O channels | nr. 1 DI for VPN Connection Enabled nr. 1 DI for general use nr. 1 DO for VPN connection in progress nr. 1 DO for general use nr. 2 DI/DO configurable |
| Ethernet ports: | nr. 2 10/100Tx on RJ45 front panel |
| Serial ports: | nr. 1 RS232/485 switchable via webserver, baud rate max 115k on connector nr. 1 RS485, baud rate max. 115k on IDC10 connector for bus and terminals nr. 1 RS485, baud rate max. 115k on terminals |
| Supported protocols: | ModBUS TCP server/client ModBUS RTU master/slave FTP/SFTP server HTTP/HTTPS server OpenVPN SSL OPC UA MQTT |
| GPS receiver: | GNSS: GPS/GLONASS/BeiDou/Galileo/QZSS up to 55 channels |
| USB port: | nr. 1 USB host 2.0 type A on side connector |
| Operating temperature: | -20°C..+65°C |
| Dimension WxHxD: | 52,5x100x112 mm |
