Contacts: 2 CO, 3 CO, 2 NO, 3 NO or 2 NO, 3 NO (contact gap 3 mm); rated load AC1 – 16 A/250 V AC or 10 A/400 V AC; coils AC or DC; indicator LED; test button
Disponibilité : 2-3 semaines
Contacts: 2 CO, 3 CO, 2 NO, 3 NO or 2 NO, 3 NO (contact gap 3 mm); rated load AC1 – 16 A/250 V AC or 10 A/400 V AC; coils AC or DC; indicator LED; test button
Disponibilité : 2-3 semaines
|
Contact data |
||
|
Number and type of contacts |
2 CO, 2 NO, 2 NO, 3 CO, 3 NO, 3 NO with contact gap ≥ 3 mm |
|
|
Rated / max. switching voltage AC |
250 V / 440 V |
|
|
Rated load (capacity) |
AC1: 16 A / 250 V AC or 10 A / 400 V AC; DC1: 16 A / 24 V DC |
|
|
Coil data |
||
|
Rated voltage |
AC: 6, 12, 24, 115, 120, 220, 230, 240 V 50/60 Hz, 400 V 50 Hz; DC: 6, 12, 24, 42, 48, 60, 110, 120, 220 V standard coil ; 12, 24, 48, 110, 220 V reinforced coil |
|
|
Rated power consumption |
AC: 2,8 VA 50 Hz; 2,5 VA 60 Hz; DC: 1,5 W; 1,7 W with contact gap ≥ 3 mm |
|
|
General data |
||
|
Electrical life resistive |
AC1: >105 16 A, 250 V AC; >105 10 A, 400 V AC |
|
|
Mechanical life (cycles) |
>107 |
|
tension : 230 Vac 24 Vdc contacts : 1 NO 2 inverseurs 2 NO 3 C/O
| Déclinaisons | Stock | Prix | Quantité | Ajouter au panier |
230 Vac
1 NO
RUC-M-3051-26-5230 |
2-3 semaines |
43,99 € |
|
|
24 Vdc
1 NO
RUC-M-3051-26-W024 |
2-3 semaines |
43,99 € |
|
|
|
230 Vac
2 inverseurs
RUC-3012-26-5230 |
2-3 semaines |
20,60 € |
|
|
|
24 Vdc
2 inverseurs
RUC-3012-26-1024 |
2-3 semaines |
20,00 € |
|
|
|
230 Vac
2 NO
RUC-M-3052-26-5230 |
2-3 semaines |
43,99 € |
|
|
|
24 Vdc
2 NO
RUC-M-3052-26-W024 |
2-3 semaines |
43,99 € |
|
|
|
230 Vac
3 C/O
RUC-3013-26-5230 |
2-3 semaines |
24,03 € |
|
|
|
24 Vdc
3 C/O
RUC-3013-26-1024 |
2-3 semaines |
20,60 € |
|
