Z-PASS2-RT-4G

https://www.inelmatec.be/7036-thickbox/z-pass2-seneca-industrial-bridge-gateway-serial-device-server-with-vpn-support-and-3g-modem-router-z-pass2-type-gateway-type-bri.jpg

IIoT Edge Gateway / Router 4G worldwide, VPN, serial device server, built-in GPS and I/O

Plus de détails...

‹ ›

Afficher toutes les images

Disponibilité : 1-2 semaines

Référence : Z-PASS2-RT-4G

En savoir plus
Fiche technique
Télécharger

Industrial Bridge/Gateway - Serial Device Server with VPN support

Gateway with VPN support - with integrated I/O, GPS receiver and 4G LTE WW modem

Z-PASS2 (latest hardware rev. Z-PASS2-4GWW) is an industrial ETH/4G LTE gateway/router with VPN support, GPS antenna and 6 integrated I/O channels: 1 DI for remote connection security interlock, 1 DI for general purpose, 1 DO for VPN connection signalling, 1 DO for general purpose and 2 DI/DO channels individually configurable as digital input or output.

The communication is guaranteed by a 4G LTE modem supporting worldwide bands, 2 Ethernet ports configurable in SWITCH or LAN/WAN mode, 3 serial ports, 1 USB host port and an integrated GPS receiver. The device can operate as Serial Device Server, it supports the LET'S platform for remote assistance and remote control for Industry 4.0 and can manage Point-To-Point or Single LAN connections also with redundant ETH/4G connection. For more information about the LETS platform click here.

Z-PASS2 supports the industrial protocols ModBUS TCP server, ModBUS RTU master/slave, FTP/SFTP server, HTTP/HTTPS server and OpenVPN encryption.
The device is easily configured via built-in Web Server.

Code:	Z-PASS2-4GWW
Description:	Industrial Gateway with VPN support - Serial Device Server with integrated I/O, GPS receiver and 4G modem
Power supply:	19..40 Vdc; 19..28 Vac
Power Consumption:	Typical 4 W @ 24Vac, Max 6 W
Insulation:	1.500 Vac
Status indicators:	Power supply/Ready to use Input/output status Remote Connection (RCD) VPN Connection (VPN) LAN/WAN (Ethernet LAN/WAN mode) SERV (VPN BOX Service) Rx-Tx Communications
Operating modes:	Bridge Gateway Router ETH/3G+ (redundant connection) Remote Virtual COM Tunnel P2P/P2MP/TCP/UDP VPN
Bands supported 4G LTE	LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28 LTE-TDD: B38/B39/B40/B41 WCDMA: B1/B2/B4/B5/B6/B8/B19 GSM: B2/B3/B5/B (for more information please see user manual) Modem certifications: Deutsche Telekom (Europe) Verizon/AT&T/T-Mobile/Sprint (North America)
I/O channels	nr. 1 DI for VPN Connection Enabled nr. 1 DI for general use nr. 1 DO for VPN connection in progress nr. 1 DO for general use nr. 2 DI/DO configurable
Ethernet ports:	nr. 2 10/100Tx on RJ45 front panel
Serial ports:	nr. 1 RS232/485 switchable via webserver, baud rate max 115k on connector nr. 1 RS485, baud rate max. 115k on IDC10 connector for bus and terminals nr. 1 RS485, baud rate max. 115k on terminals
Supported protocols:	ModBUS TCP server/client ModBUS RTU master/slave FTP/SFTP server HTTP/HTTPS server OpenVPN SSL OPC UA MQTT
GPS receiver:	GNSS: GPS/GLONASS/BeiDou/Galileo/QZSS up to 55 channels
USB port:	nr. 1 USB host 2.0 type A on side connector
Operating temperature:	-20°C..+65°C
Dimension WxHxD:	52,5x100x112 mm
