- uitgang: RC150 - 100 mV / kA / RC190 - 333 mV / kA
- versie RC150 vanaf lengte 25 cm, interne diameter 8 cm,
tot lengte 180 cm, interne diameter 57 cm
- versie RC190 - vanaf lengte 30 cm interne diameter 9 cm
tot lengte 180 cm interne diameter 57 cm
- temperatuur: -30°C +80°C
- beschermingsgraad: IP67
- 1000 VRMS CAT III; 600 VRMS CAT IV
- testspanning: 7400 Vrms/ 1 min
| Coil length | From 25 to 300 cm (internal Ø up to ~57cm) |
| Coil diameter | 8.3 ±0.2 mm |
| Output level (RMS) | 100 mV / 1 kA @50Hz (standard) |
| Coil resistance | From 70 to 900 Ω |
| Positioning error | Better than ±1% of reading (with 15 mm diameter cable) |
| Frequency range | Approx 40 Hz to 20 kHz |
| Working voltage | 1000 VRMS CAT III; 600 VRMS CAT IV |
| Test Voltage | 7400 Vrms/ 1 min |
| Operating Temperature | From -30°C to +80°C |
| Protection Degree | IP67 |
stroomingang : L=25 cm, Ø int. 8 cm L=35 cm, Ø int. 11 cm L=40 cm, Ø int. 12 cm L=60 cm, Ø int. 19 cm L=90 cm, Ø int. 28 cm L=120 cm, Ø int. 38 cm L=180 cm, Ø int. 38 cm
| Uitvoeringen | Stock | Prijs | aantal | toevoegen |
L=25 cm, Ø int. 8 cm
RC150-025-100-3M |
1-2 weken |
138,46 € |
|
|
L=35 cm, Ø int. 11 cm
RC150-035-100-3M |
1-2 weken |
144,00 € |
|
|
L=40 cm, Ø int. 12 cm
RC150-040-100-3M |
1-2 weken |
144,00 € |
|
|
L=60 cm, Ø int. 19 cm
RC150-060-100-3M |
1-2 weken |
152,31 € |
|
|
L=90 cm, Ø int. 28 cm
RC150-090-100-3M |
1-2 weken |
214,62 € |
|
|
L=120 cm, Ø int. 38 cm
RC150-120-100-3M |
1-2 weken |
346,16 € |
|
|
L=180 cm, Ø int. 38 cm
RC150-180-100-3M |
1-2 weken |
556,62 € |
|
