type |
|
Modem |
RS232/ RS485 |
MPI/ Profibus |
Ethernet 100Mbit |
WAN |
OpenVPN |
|---|---|---|---|---|---|---|---|
| MDH815 | analog | - | - | 4x | - | ja | |
| MDH819 | 3G | - | - | 4x | - | ja | |
| MDH858 | LTE | - | - | 4x | - | ja | |
MDH815
| spanning | 10 - 30 V DC |
| stroom bij 24 V | 300 mA |
| beschermingsgraad | IP 20 |
| Operational environment | Dry environment |
| werkingstemperatuur | 0...50 °C |
| stockage temperatuur | -20...+60 °C |
| vochtigheid | 0…95% noncondensing |
| gewicht | 650 g |
| afmetingen | 124 mm x 48 mm x 124 mm (H x W x D) |
| Modulatie type | V.21, V.22, V22bis, V.23, V.32, V.32bis, V.34 |
| Data compressie | V.42bis, MNP5 |
| Error correctie | MNP 2-4, V.42 LAPM |
| Dialing methode | DTMF/Pulse |
| Communicatie certificaat | CTR 21 approval |
| LAN peort | 10/100 MBit/s full- and half duplex operation, auto-detection patch cable/cross-over cable |
| VPN | OpenVPN, 1 Tunnel |
| Encryptie methode | Blowfish, AES/DES/3DES |
| Encryptie algorithmes | MD5, SHA1 |
| Authorisatie | PSK, X.509 |
| Firewall | 1:1 NAT, IP filtering, Port forwarding, state-full-inspection |
| Services | DHCP server, DHCP client, DNS server, NTP client, PPP server, DynDNS |
| USB Host Interface | USB Host 2.0 |
| ingangen | 4 (Low 0-3,2 V, High 8-30 V) |
| uitgangen | 2 (50 mA @ 12 V / 100 mA @ 24 V) |
| keuringen | EN 61000-6-4, EN 61000-6-2 |
| Operationele landen | 240 landen |
MDH819
| spanning | 10 - 30 V DC |
| stroom mA (bij 24 V) | 400 |
| beschermingsgraad | IP 20 |
| werkings omgeving | droge omgeving |
| werkingstemperatuur | 0...50 °C |
| stockage temperatuur | -20...+60 °C |
| vochtigheid | 0…95% |
| gewicht | 650 g |
| afmetingen | 124 mm x 48 mm x 124 mm (H x W x D) |
| GPRS Klasse | 10 (max. 85,6 kBit/s) |
| EDGE Klasse | 10 (max. 236,8 kBit/s) |
| HSxPA Klasse | Downlink HSDPA Category 14 (21,0 Mbps),Uplink HSUPA Category 6 (7,56 Mbps) |
| ondersteunde netwerken | 800, 850, 900, AWS 1700, 1800, 1900, 2100 MHz |
| LAN peort | 10/100 MBit/s full and half duplex operation, auto-detection patch cable / cross-over cable |
| VPN | OpenVPN, 1 Tunnel |
| Encryptie methode | Blowfish, AES, DES/3DES |
| Encryptie algorithme | MD5, SHA1 |
| Authorisatie | PSK, X.509 |
| Firewall | 1:1 NAT, IP filter, Port forwarding |
| Services | DHCP server, DHCP client, DNS server, NTP-client, PPP server, DynDNS |
| USB Host Interface | USB Host 2.0 |
| ingangen | 4 units (Low 0-3,2 V, High 8-30 V) |
| uitgangen | 2 units 50 mA @ 12 V / 100 mA @ 24 V |
| keuringen | EN 61000-6-4, EN 61000-6-2; For details, see Declaration of Conformity in the download portal |
| Operationele landen | wereldwijd |
MDH858
| spanning | 10 - 30 V DC |
| stroom | 400 mA (with 24 V) |
| beschermingsgraad | IP 20 |
| werkingsomgeving | droge omgeving |
| werkingstemperatuur | 0...50 °C |
| stockage temperatuur | -20...+60 °C |
| vochtigheid | 0…95% |
| gewicht | 650 g |
| afmetingen | 124 mm x 48 mm x 124 mm (H x W x D) |
| GPRS Klasse | 12 (max. 86,5 kBit/s) |
| EDGE Klasse | 12 (max. 236,8 kBit/s) |
| HSxPA Klasse | Downlink HSDPA Category 8 (7,2 Mbps), Uplink HSUPA Category 5 (2 Mbps) |
| LTE Klasse | 3 (max. 100 Mbps Downlink; 50 Mbps Uplink) |
| ondersteunde netwerken | enkel EU |
| LTE 800/900/1800/2100/2600 MHz | |
| WCDMA 900/2100 MHz | |
| GSM/GPRS/EDGE 900/1800/1900 MHz | |
| LAN poort | 10/100 MBit/s full and half duplex operation, auto-detection patch cable / cross-over cable |
| VPN | OpenVPN, 1 Tunnel |
| Encryptie methode | Blowfish, AES, DES/3DES |
| Encryptie algorithmes | MD5, SHA1 |
| Authorisatie | PSK, X.509 |
| Firewall | 1:1 NAT, IP filter, Port forwarding |
| Services | DHCP server, DHCP client, DNS server, NTP-client, PPP server, DynDNS |
| USB Host Interface | USB Host 2.0 |
| ingangen | 4 units (Low 0-3,2 V, High 8-30 V) |
| uitgangen | 2 units 50 mA @ 12 V / 100 mA @ 24 V |
| keuringen | EN 61000-6-4, EN 61000-6-2; For details, see Declaration of Conformity in the download portal |
| Operationele landen | EU |
modem : 4G LTE
| Uitvoeringen | Stock | Prijs | aantal | toevoegen |
4G LTE
MDH 858 EU |
1-2 weken |
1 483,22 € |
|
